High-Bay Lights

High Bay Light

The Most Energy Efficient High Bay Lights On The Market: Excellent for warehouses, assembly lines, factories, and extreme cold/hot environment ( -60°C~80°C ).

True Color

The Most Energy Efficient High Bay Lights On The Market: Excellent for warehouses, assembly lines, factories, and extreme cold/hot environment ( -60°C~80°C ).

Color Temperature

2700K Incandescent lamps
3000K Warm White Compact Fluorescent Lamps
4300K Moonlight
5000K Daylight At Noon
6000K-7500K Cloudy Daylight

World Leading Efficacy

Efficiency – 138.6 lm/wWith our cutting edge technologies, our high bay lights bring you the world leading efficiency, 138 lm/W. At the beginning of 2015, XLEDIA announced its high bay light, X120N, which consumed 120W and generated 16,632 lm. It has become a beacon to the industry. Higher efficiency, more energy saved.

Satisfaction and Safety

3 Years Warranty & PSE, UL certified. For customers’ satisfaction and quality assurance, XLEDIA provides 3 years warranty with the usage of 24hrs a day and 7 days a week. XLEDIA High Bay Lights were ETL and PSE certified, compliance to North American and Japan safety standards.

Best Quality LED Chips

87,600 hours Lifespan*
XLEDIA used nothing but the best quality LED chips from the leading LED manufacturer in Japan to deliver the true light color and the best efficiency with the 87,600 hours lifespan.
*Light decay was certified less than 6% after 87,600 hours at 50°C.

Excellent Light Distribution

No Glare.
High bay lights generate very high lumen with great risk of glare. XLEDIA’s patented lens were accurately designed and manufactured in order to control and deliver the light to the desired directions and to rminimize the glare. It surely brings you visual comfort lighting.

Extremely Cold And Hot Environment Suitable

Working Temperature Rang – -60°C (-76°F)to 50°C (122°F)
XLEDIA’s high bay lights have been certified to work with the extreme temperature. It is suitable for the environment from -60°C (-76°F) to 50°C (122°F). Excellent for cold storages and steel mills.

Dust proof

XLEDIA’s excellent thermal management enable its outstanding performance in a dirty environment, such as steel mills. After years usage, the dust might cover the high bay lights, but it won’t damage its outstanding performance.
With the same power consumption, our high bay lights can illuminate the desired area with higher Illuminance. Here are few comparisons to show how efficient our high bay lights can be to illuminate your facilities by comparing the performance with one of major players.

Performance Comparison See how our high bay light saves you money.

Comparison 1

XLEDIA (120W) versus P company (115W)

In the space of 32mx20mx(H)8m (105x66x26 ft), 30 pieces of XLEDIA’s high bay lights can reach 600 lx on the ground but the ones from P company can only reach 500 lx.

Comparison 2

XLEDIA (120W) versus P company (115W)

In order to reach 600 lx lighting on the ground, 35 pieces of high bay lights from P company are needed but only 30 pieces of XLEDIA’s high bay lights are needed to have the same performance. XLEDIA can save you 10% energy and 15% luminaire purchasing cost.

Instant On.

It takes 20minutes for mercury lamps to completely on. LED high bay lights can be on instantly.

Here are few demo applications to show how to use our low/high bay lights for your facilities.

5 Meters (17ft) High Facility

Our standard setup for a facility with a space, 32x20x5m (105x66x17ft), to reach mean illuminance, 200 lx.

8 Meters (26ft) High Facility

Our standard setup for a facility with a space, 32x20x5m (105x66x17ft), to reach mean illuminance, 200 lx.

10 Meters (33ft) High Facility Advanced

Our ADVANCED setup for a facility with a space, 32x20x10m (105x66x33ft), to reach mean illuminance, 500 lx. It is recommended for gymnasiums, shipping centers, and so on.

8 Meters (26ft) High Facility

Our standard setup for a facility with a space, 32x20x5m (105x66x17ft), to reach mean illuminance, 200 lx.

16 Meters (52ft) High Facility Standard

Our standard setup for a facility with a space, 50x25x16m (164x82x52ft), to reach mean illuminance, 300 lx. It is recommended for steel mills, power plants, vehicle manufacturers, and so on.

40 Meters (131ft) Super High Facility Standard

Our standard setup is for a facility with a space, 50x25x40m (164x82x131ft), to reach mean illuminance, 300 lx. It is recommended for buildings with very high ceilings such as steel mills, and power plants.

Extra 30% Energy Saving For Logistic Industry

From XLEDIA

New Arrival

R Type

Why R Type?

The traditional high bay lights distribute light in a cone shape from top to bottom. For logistic industry, there are many racks installed in warehouses. Great portion of light is wasted on the top of racks. XLEDIA introduces new high bay lights applying advanced asymmetric lens designs to distribute light more effectively on the aisles, instead of wasting light on the top of racks, to save you more energy. These high bay lights are highly optimized for racked warhouses and the illumination of drive ways.

Feature

With special designed asymmetric lens, XLEDIA efficiently reduced the wasted light and re-focus light on the area desired. The luminaires on the left are the traditional LED high bay lights and XLEDIA X120N-R are on the right. The distance is 7 meter between luminaires and all luminaires on the left and right aisles are 120W/16600 lm at 10 m high. As shown, the X120N-R can provide better luminance and cover wider area and save you more money.
As shown, the X120N-R can easily reach 300 lx on ground at 10 high due to its special lens designs. The traditional one with same energy consumption and lumen can only reach 200 lx.
A warehouse which is 50 meters(164 feet) long and 10 meters(33 feet) high may need 10 mercury lights (500W), 5 meters(16.4 feet) between luminaries. If replace them by X120NR(120W), due to its wide range illumination, the distance between luminaries can be extended to 7 meters(23 feet), and you need only 7 pieces. That is extra 30% savings.
The figure below shows the illumination comparison of 500W mercury lamps and X120NR. The brightness in the yellow area is above 200 lx. 7 pcs of X120NR can perform as well as 10 pcs of 500W mercury lamps do. You can save 4,160W*. That means you can save USD1,640/year if you use 10 hours per day. *calculation:500W×10ー120W×7=4,160W
